ANPR camera STP A0RT for Complete solution for traffic 2022

Radar Pole Module

  • 4D Advanced Doppler Radar 66 – 77 GHz
  • Synthetic orientation of the working lobe for quick adaptation to the street installation
  • Integrated 2Mpixel Color Camera to support vehicle tracking – people in the scene
  • 2 lane coverage
  • Single or two-way detection
  • On-board neural algorithms for video tracking validation associated with radar tracking
  • Speed measurement from 20 to 250 Km / h
  • Speed Accuracy <+/- 1% or <+/- 0.28m / sec (greater than)
  • Range Accuracy <+/- 2.5% or <+/- 0.25m / sec (greater than)
  • Operating distance 15-30m
  • Working frequency 66GHz
  • Vehicle classification in 4 radar classes + 6 room classes (daytime);
  • Length of vehicles;
  • Counting by lane
  • Occupancy statistic by lane
  • Real-time video streaming H264 ONVIF S profile
  • On-board memory up to 2GB
  • POE power supply
Processor QuadCore ARM 1,2GHz
Neural graphic co-processor
Memory Ram 4GB, Flash 8GB
Camera Integrated 2 Megapixel color 60fps
Lens fixed S type;
Streaming configurable real-time H264 ONVIF S profile
Transmit frequency 66 – 77 GHz
Bandwidth selectable from  1-250 MHz
Output power (EIRP) EIRP Adjustable P.out 8 -20 dBm
Phase noise @1KHz  -63 dBc/Hz
Noise figure @100KHz SSB 11 – 17 dB
System Antenna Pattern (10dB)
Azimut   +/-12  –  +/-15 deg.;
Elevation   +/-7  –  +/-10 deg.;
LAN and ports Ethernet Port, RS485 Port
Dimensions (h/l/w) 120x180x90 mm
Weight 0,7 Kg. approx.
Power Supply 9-36 Vdc – 5W or POE
Operating temperature -20° + 60°C;
Protection IP67
Certifications ETSI 300/440 compliant with 50MHz bandwidth
